MGA36700 - Square D - Molded Case Circuit Breaker I-Line Plug-In - 700 Amp - 3 Pole - 600 Volt
New
$3,300.00
Sale price
$3,300.00
Regular price
Skip to product information
MGA36700 - Square D - Molded Case Circuit Breaker I-Line Plug-In - 700 Amp - 3 Pole - 600 Volt
$3,300.00
Sale price
$3,300.00
Regular price
Product images are representative only. Actual product may vary.
Description
Delivering robust performance for commercial facilities, the Square D MGA36700 is a 700A, 3-pole electronic trip circuit breaker. It features an ET 1.0 microprocessor trip unit for precise long-time and instantaneous (LI) sensing. Designed with an I-Line plug-on connection, it installs into Square D I-Line panelboards and switchboards, functioning as a drop-in replacement for discontinued MA36700 breakers. It provides an interrupting capacity of 35 kAIC at 480VAC for reliable protection.Specifications
| Brand | Square D |
| Series | MGA |
| Amperage | 700A |
| Voltage | 240VAC, 480VAC, 600VAC |
| Poles | 3 |
| Phase | 3 |
| AIC Rating | 65kA @ 240VAC, 35kA @ 480VAC, 18kA @ 600VAC |
| Mounting Style | I-Line |
| Terminal Type | Lugs |
| For Use With | Square D I-Line Panelboards, Square D I-Line Switchboards |
| Trip Technology | Electronic Trip |
| Trip Function Code | LI |
| Trip Function | Long-Time, Instantaneous |
| Trip Adjustability | Fixed Thermal, Adjustable Magnetic |
| Wire Gauge | 3x 3/0 AWG - 500 kcmil (Al/Cu) |
| Max Wire | 500 kcmil |
| Min Wire | 3/0 AWG |
| Available Options | Shunt Trip, Auxiliary Switch, Undervoltage Release, Alarm Switch, Padlock Attachment |
| Accessories | Lugs (Load Side) |
| Standards | CSA C22.2 No. 5, IEC 60947-2, NEMA AB 1, UL 489 |
| Approval | CE, CSA, IEC, NOM, UL |
| Temp Rating | -25C to 70C |
| Construction Features | HACR Rated, Mercury Free, PVC Free, Push-to-Trip, Visual Trip Indicator, 80% Rated |
